Face Plate: 170Lx50WX44H(mm)
Bracket: 170Lx50WX30(mm)
Bolt: 15 mm
Voltage: 12VDC
Start Current: 900mA
Current: 120mA Signal output
Time Delay: Yes, 0,2.5,7 sec
Open Wire: Yes
Solid Bolt: Polishing housing, 1000Kg Holding Force
Suitable For: Woodeng Door,Glass Door,Metal Door,Fireproof Door
Induction Distance: 8mm
Special Designed: Tested to 500000 cycles
Face Place Material: Stainless Steel
Weight: 1.2kg
